General

The basic settings are described in detail in the ibaPDA manual. Normally, the preset values do not need to be changed.

In the field “No. cameras”, you can configure the number of cameras to be configured. The minimum value is 16. When connected to the video server, ibaPDA will automatically set the number of cameras to the correct value, if a higher number of cameras is available.

Note
	The timebase in this case sets the period for writing the synchronization data in the data file. It is recommended setting this timebase at least half the timebase of the fastest camera or lower. Example: Camera with 25 fps (= 40 ms) -> recommended time base ≤ 20 ms Camera with 300 fps (= 3.33 ms) -> recommended time base ≤ 2 ms
