The digital signal table is automatically adjusted for each terminal type. The terminals are displayed in the order in which they are added.

The "K bus valid" signal is available by default and can be enabled/disabled.

As long as the K-bus has been properly established and is running, this signal is "True". If a K-bus error occurs, the "K-bus valid" signal changes to "False". See also chapter K-bus error.

The meaning of the columns is as in the Analog tab, see chapter ibaW-750 – Analog tab. Here, however, the columns Unit, Gain and Offset are not available.
