Acquisition of the raw values of voltage and current at the input modules
-
Calculation of the characteristic values in ibaPQU-S
-
Configuration of the modules, configuration of data recording, acquisition and visualization of the measured and calculated characteristic values in ibaPDA
-
Transferring the configuration and data with 32Mbit Flex
-
Analysis, evaluation and if applicable reporting in ibaAnalyzer
