Name

You can enter a signal name and additionally two comments when clicking on the  symbol in the Name field.

Debounce filter

In the drop-down menu, you can choose the operating mode for the debounce filter. The following settings are available: Off, Stretch rising edge, Stretch falling edge, Stretch both edges, Delay both edges.

See Debounce filter inputs.

Debounce time (µs)

Here, you can define the debounce time in µs

Active

Enabling/disabling the signal
