The following illustration shows the front view of the module ibaMS8xIEPE .
|
1 |
Fixing screws |
4 |
Connector X1 of analog inputs 00…03 |
|
2 |
Operating status indicator L1…L4 |
5 |
Connector X2 of analog inputs 04…07 |
|
3 |
Status LED L26…L33 of analog inputs 00…07 |
||
